Meiji EMZ-5TRD + MA502 + PK

Description

The EMZ-5TRD body offers detent click-stops and delivers sharp, high-contrast images and an excellent zoom range of 6.5:1 that provides exceptionally high resolution images all throughout the zoom range. The EMZ-5TRD employs Greenough optics, for improved image flatness and contrast. As a result images are brighter and more distinct even at the periphery of the field of view. With the large zoom range, the EMZ-5TRD offers high resolution observation in precision-oriented semi-conductor, medical device and routine inspection. In addition to it’s compact design and versatility a wide variety of auxiliary lenses and stands are available to allow the user to customize their desired working distance to adapt to almost any application.

An extended working distance ergonomic pole stand with 250mm pole and “F” focusing holder mounted on a ergo base. Supplied with one 94.5mm diameter reversible black and white stage plate and two stage clips. The PK can be accessorized with an optional 20 watt halogen incident illuminator with stand alone power supply.

Included is the MA502 Super Widefield Eyepiece 10X (pair) with 25mm reticle mount Field No. 23.0, Eye Relief 16.0, Focal Length 25.0
